Product Group: Earthing & Lighting Protection Systems
DC TAPE CLIP
Dc tap clip are copper or Aluminium alloys
for secures the tape conductor the tape fits
into the support and is secured by tow screw
|
Tape size (mm)
|
Wt/Kg. Each
|
| 20x3 |
0.060 |
| 25x3 |
0.065 |
| 25x4 |
0.070 |
| 25x6 |
0.080 |
| 31x3 |
0.090 |
| 31x6 |
0.100 |
| 38x3 |
0.120 |
| 38x5 |
0.120 |
| 38x6 |
0.140 |
| 50x3 |
0.150 |
| 50x4 |
0.150 |
| 50x6 |
0.160 |
Material : copper alloys, ASM C83600,BS EN 1982,LG-2
Bolt : brass or steel
|
